YAG:Ce - LED Phosphor
Y3Al5O12:Ce
- Catalog Number
- YT-5720
- CAS Number
- 163584-80-3
- Purity
- 99.9
- Formula Mass
- 733.73 g/mol
- Physical Form
- white / yellow powder
Product Description
Cerium doped Yttrium Aluminum Garnet is available as a 99.9 pure (metals basis) powder in large batch quantities for use in white LED lamps and high pressure mercury lamps. Lorad Chemical has developed a novel process for the synthesis of uniform small particle size YAG:Ce phosphor powder. When incorporated into blue LEDs, the YAG:Ce converts some of the blue light to yellow, such that the emitted light is white.
- Market Focus: Security Phosphors
- Categories: Oxides
Additional Properties & Information
| Typical Purity | 99.9 |
|---|---|
| Appearance | white / yellow powder |
| Density | 4.55 g/cm³ |
| Formula Mass | 733.73 g/mol |
| Crystal System | Cubic |
Product Specifications
| Formula Mass | 733.73 g/mol |
|---|---|
| Purity | 99.9 |
| Density | 4.55 g/cm³ |
| Crystal System | Cubic |
| Refractive Index | 1.82 at 550nm |
Identifiers
| Formula | Y3Al5O12:Ce |
|---|---|
| CAS Number | 163584-80-3 |
