Indium Tin Oxide
In2O3:SnO2
- Catalog Number
- IN-2310
- CAS Number
- 50926-11-9
- Purity
- 99.99
- Physical Form
- Available as a powder or a nano-powder. Also available as tablets - In:Sn=90:10 (Customized Ratios).
Product Description
Indium Tin Oxide is available as 99.99 pure (metals basis) powder, nano-powder, or tablets in large batch quantities. Indium Tin Oxide is a doped n-type semiconductor with a large bandgap of around 4eV. It is mostly transparent in the visible part of the spectrum. ITO is a custom synthesized material and is available in customized compositions, In2O3:SnO2 = 90:10 , 95:5 or as required by the customer. Lorad Chemical has developed a novel proprietary method for sintering ITO compositions to very high density. At this time, small sintered discs are available.
- Market Focus: Refractory Oxides, Electro Conductive Powders, Thin Film Coatings
- Categories: Oxides
- Synonyms: ITO
Additional Properties & Information
| Typical Purity | 99.99 |
|---|---|
| Appearance | Available as a powder or a nano-powder. Also available as tablets - In:Sn=90:10 (Customized Ratios). |
| Density | 1.20 g/cm³ |
Product Specifications
| Purity | 99.99 |
|---|---|
| Density | 1.20 g/cm³ |
| Refractive Index | 2 at 500nm |
| Transmission Range | 400 - 1000nm |
| Evaporation Temperature | ~600ºC |
| Evaporation Source | e-beam |
| Available as Tablet | Yes |
Identifiers
| Formula | In2O3:SnO2 |
|---|---|
| CAS Number | 50926-11-9 |
| EC / List Number | 610-589-1 |
Applications
Refractory Oxides
View application
Electro Conductive Powders
View application
Thin Film Coatings
View application
<p class="p1">ITO has high electrical conductivity and optical transparency, making it useful in thin-film applications for flat-panel displays, windows, polymer-based electronics or thin-film photovoltaics. Thin-films of ITO can also be used in light-emitting diodes (as an anode), antistatic coatings, infrared-reflecting coatings, and electro-magnetic interference shielding.</p>
