Gallium Phosphide
GaP
- Catalog Number
- GA-2026
- CAS Number
- 12063-98-8
- Purity
- +99.9
- Formula Mass
- 100.7 g/mol
- Physical Form
- pale orange powder
Product Description
- Market Focus: Thin Film Coatings, Polycrystalline Ceramics
- Categories: Phosphides
Additional Properties & Information
| Typical Purity | +99.9 |
|---|---|
| Appearance | pale orange powder |
| Density | 4.14 g/cm³ |
| Formula Mass | 100.7 g/mol |
| Melting Point | 1,457°C |
| Crystal System | Tetrahedral |
Product Specifications
| Formula Mass | 100.7 g/mol |
|---|---|
| Purity | +99.9 |
| Density | 4.14 g/cm³ |
| Melting Point | 1,457°C |
| Crystal System | Tetrahedral |
| Refractive Index | 4.3 at 263nm (UV), 3.45 at 55nm (green), 3.19 at 840nm (IR) |
Identifiers
| Formula | GaP |
|---|---|
| CAS Number | 12063-98-8 |
| EC / List Number | 235-057-2 |
Applications
<p>This material is used in red, orange, and green LEDs.</p>
